DetailedIDER308
| ◆ LED Downlight used in directional local lighting places. ◆ Designed in accordance with international and industry standards. ◆ Light source with high quality COB LED. ◆ Light body using aluminum alloy materials. ◆ Optical components using high efficiency reflector cup, you can choose different beam angles. ◆ Thermal structure design and reasonable. ◆ Driver no flicker, quick start. | ||||
| Model(型号) | IDER308-12W | IDER308-18W | IDER308-24W | IDES309-30W |
| Input Voltage (输入电压) | AC160-240V | |||
| Power (LED 功率) | 12W | 18W | 24W | 30W |
| LED | Epistar | |||
| Dimension (尺寸）/mm | ∅110x40 | ∅165x40 | ∅185x40 | ∅200x40 |
| Cut-out（开孔）/mm | ∅100 | ∅135 | ∅165 | ∅175 |
| CCT (色温) | 3000-6000K | |||
| Beam angle （光束角） | / | |||
| Material（材质） | Plastic (IP20) | |||
| Model(型号) | IDES308-12W | IDES308-18W | IDES308-24W | IDES309-30W |
| Input Voltage (输入电压) | AC160-240V | |||
| Power (LED 功率) | 12W | 18W | 24W | 30W |
| LED | Epistar | |||
| Dimension (尺寸）/mm | 120x120x40 | 150x150x40 | 180x180x40 | 200x200x40 |
| Cut-out（开孔）/mm | ∅100 | ∅135 | ∅165 | ∅175 |
| CCT (色温) | 3000-6000K | |||
| Beam angle （光束角） | / | |||
| Material（材质） | Plastic (IP20) | |||
